Hwashi Electric Resistance Welding Machine, Metal Round Wire Butt Welding Machine, Key Soldering Butt Welder

Name: Hwashi Electric Resistance Welding Machine Metal Round Wire Butt Welding Machine Key Soldering Butt Welder
Brand: HWASHI
Price: 1 USD

Quality Hwashi Electric Resistance Welding Machine, Metal Round Wire Butt Welding Machine, Key Soldering Butt Welder for sale

Brand Name : HWASHI

Certification : CE/CCC/ISO

Place of Origin : China

MOQ : 1 set

Price : negotiation

Payment Terms : L/C, T/T

Supply Ability : 50 sets per month

Delivery Time : 7-30 working days after received your payment

Packaging Details : sea worthy wooden package

Product Name : Mass Production in China Steel Wire Butt Welding Machine Sell Like Hot Cakes

Warranty : 12 Months

Condition : New

Service Life : 8-10 Years

Weight (Kg) : 120kg

Power (Kw) : 50kw

Dimensions : 1000*1000*1500mm

Contact Now

Hwashi Electric Resistance Welding Machine ,Metal Round Wire Butt Welding Machine,Key Soldering Butt Welder

Product description

Under the operation of transformer, Cu-Al tube butt welding machine utilizes the general mains supply to lower the voltage and increase the electric current. Such kind of low voltage but large current will be transmitted from the electrode to the linked point of two work pieces. On the linkage, due to the resistance of work piece, high temperature will occur so the metal will therefore generates high heat to make the work pieces in molten condition. Thus, the purpose of welding the two work pieces is achieved.

No.	Item	Parameters
1	Input Power	50KVA
2	Input Voltage	380V Single-phase 50Hz
3	Input Current	135A
4	Output Voltage	AC5.6V
5	Max Short Circuit Current	21000A
6	Welding Models	16 types
7	Welding Cylinder	¢50x2-80mm
8	Pushing Cylinder	¢80-80mm
9	Dimension (LWH)	1000x1000x1500mm
10	Weight	120kg
